VLX 100 Arched / Custom Door

VLX 100 Arched / Custom Door in Pinecrest, FL | Sightline Windows & Doors Pinecrest

The VLX 100 Arched / Custom Door is a CNC-bent aluminum arched entryway that turns a standard opening into a curved architectural statement with genuine structural precision. Homeowners in Pinecrest choose this door when they want an entrance that reads as intentional design, not afterthought. Sightline Windows & Doors Pinecrest is an authorized ViewLux installation partner, which means we source directly from the manufacturer and install to warranty-preserving standards. We’ve fitted these arched systems in Pinecrest estates near Coral Gables borders, in Palmetto Bay-adjacent renovations, and in new builds throughout the village where architects spec radius openings. If you’re researching arched entry systems for a Pinecrest home, call us at (786) 442-3200 to schedule a free on-site measurement and written estimate.

Call (786) 442-3200

Product Overview - VLX 100 Arched / Custom Door

The VLX 100 Arched / Custom Door starts with a single aluminum extrusion and bends it to a precise radius using CNC-controlled forming. That matters because hand-bent or segmented arched frames develop stress fractures at the apex, particularly under Pinecrest’s seasonal wind loads and afternoon thermal expansion. ViewLux’s process maintains uniform wall thickness through the curve, so the structural integrity you get in a straight jamb persists through the arch.

Buyers in Pinecrest gravitate toward this series for two reasons. First, the profile is slender at 2.56 inches wide, which keeps sightlines clean and lets the glass or the curve itself command attention. Second, the custom fabrication means you’re not selecting from a catalog of preset radius dimensions. We measure your rough opening, the architect’s drawings, or an existing masonry arch, and the frame is built to that specification.

The 0.098-inch wall thickness gives the extrusion enough mass to resist racking without adding dead load to the header. In Pinecrest, where many homes date to the 1960s and 70s with original headers sized for lighter assemblies, that weight discipline matters. We’ve replaced undersized wood arches in Pinecrest’s older ranch-style homes where the original opening had sagged, and the VLX 100’s rigidity let us restore the original radius without rebuilding the header.

This door fits where a flat system would read as compromise: Mediterranean revivals, contemporary builds with barrel-vault entries, transitional homes where the architect wants a single curved element to soften an otherwise rectilinear facade. It is not a retrofit afterthought. It is a primary design decision.

Technical Specifications

Before

After

Performance Features

Thermal Efficiency

The VLX 100 uses a true thermal break that separates interior and exterior aluminum surfaces, cutting conductive heat transfer. NFRC-rated performance means the numbers are third-party verified, not marketing claims. In Pinecrest, where summer attic temperatures push cooling loads for weeks at a stretch, that break keeps the interior frame surface closer to room temperature and reduces condensation potential.

Acoustic Performance

Multi-chamber extrusion geometry and laminated glass options dampen exterior noise. We’ve installed these on Pinecrest properties adjacent to US-1 and Old Cutler Road where traffic drone was the client’s primary complaint. The mass of the 0.098-inch wall plus proper gasketing delivers measurable reduction, not just a thicker door feel.

Airtightness & Weather Seal

Compression seals at the meeting stiles and bulb seals at the frame perimeter maintain positive closure pressure. The AAMA 812 low-expansion foam sealant we apply at installation fills irregularities in the rough opening without distorting the frame. That matters in Pinecrest’s older concrete block construction where walls are rarely perfectly flat.

Waterproofing

Integrated sill dams, weeped subsills, and sloped head flashings direct water to the exterior. The arched geometry complicates drainage compared to a rectangular door, so ViewLux engineers the head profile with a continuous slope even through the radius. We verify water management with a hose test before we sign off on any Pinecrest installation.

Wind Resistance

The system is wind-load rated for local code requirements. The custom-fabricated arch distributes lateral load through the jambs rather than concentrating stress at the crown. In Pinecrest, where the Miami-Dade County wind zone governs, that structural continuity is not optional. We pull permits and submit engineer-stamped drawings where the span requires it.

Security & Hardware

Multi-point locking hardware engages at the sill, center, and head. The laminated glass option adds forced-entry resistance and holds shards in place if broken. For Pinecrest homeowners who travel seasonally, we can integrate the VLX 100 with smart lock systems that maintain the clean face aesthetic.

Color & Glass Options

Premium Black reads contemporary and conceals the frame against dark-tinted glass. We’ve used this on Pinecrest modern builds where the architect wanted the door to disappear into shadow.

Pure White suits coastal traditional and Bermuda-style homes common in eastern Pinecrest near the Deering Estate area. It reflects heat and stays cleaner-looking in high-UV exposure.

Anodized Silver is the raw aluminum aesthetic, mill-finished and chemical-resistant. Good for industrial or minimalist applications where paint reads as unnecessary.

Bronze warms the metal tone without imitating wood. It bridges Mediterranean and transitional palettes and ages gracefully in Pinecrest’s salt-air environment.

Champagne is a lighter metallic that complements limestone and coral stone cladding without competing. Popular in Pinecrest’s newer construction with lighter stucco palettes.

Teak Wood is a powder-coated finish with grain texture, giving the warmth of wood with aluminum’s maintenance profile. For Pinecrest homeowners who want the appearance of a wood arched door without the swelling, checking, and refinishing cycle.

Glass selection depends on exposure and privacy needs. Clear for maximum daylight and views. Frosted or Obscure for privacy at street-facing entries. Low-E for west and south exposures in Pinecrest where afternoon solar gain is aggressive. Tempered for safety at human-height panels. Laminated for impact resistance, security, and acoustic control.

Installation by Sightline Windows & Doors Pinecrest in Pinecrest

We install every VLX 100 Arched / Custom Door to AAMA 2400/2410 standards, which governs how fenestration interfaces with the wall assembly. That is not a suggestion. ViewLux’s manufacturer warranty requires documented compliance, and we provide that documentation.

Our process starts with a pre-install inspection of the rough opening. On arched units, we verify the radius matches the shop drawings within 1/8 inch, because a custom frame will not tolerate field adjustment the way a rectangular unit might. We check the header for level, the jambs for plumb, and the opening for square. In Pinecrest’s older homes, we often find that original masonry arches have settled or that previous remodels compromised the supporting structure. We flag those issues before the frame arrives, not during installation.

Setting the frame, we shim at structural points, not randomly, and we anchor through the jamb into structural substrate, not just finish material. The AAMA 812 low-expansion foam sealant goes in all perimeter joints. Standard expanding foam distorts aluminum jambs. Low-expansion product fills without pressure. We tool the sealant flush and verify continuity around the entire arch, which is harder to inspect than a straight head.

Final steps: hardware adjustment, sweep contact verification, multi-point lock synchronization, and a water test with a calibrated spray pattern. We clean the site and leave the protective film in place for the builder or homeowner to remove after construction dust settles.

Improper installation voids the ViewLux warranty. That is explicit in their terms. Sightline Windows & Doors Pinecrest maintains authorized-partner status by honoring those terms on every Pinecrest job. We’ve seen homeowners attempt to save money with unqualified installers, then call us when the frame leaks or the arch distorts. By then, the warranty is gone and the remediation costs more than professional installation would have.

Pinecrest’s climate adds specific considerations. The combination of high humidity, salt air, and intense UV means sealants and finishes degrade faster than inland markets. We select compatible materials and we know which Pinecrest neighborhoods sit on fill soils that shift seasonally, stressing rigid frames. That local knowledge is part of what you get when you work with a Pinecrest-based installer rather than a traveling crew.

Frequently Asked Questions - VLX 100 Arched / Custom Door

What is the lead time for the VLX 100 Arched / Custom Door?

Lead time typically runs 8 to 12 weeks from signed approval of shop drawings, because each arched unit is custom fabricated to your opening’s exact radius and span. Standard rectangular doors ship faster, but the CNC bending and quality verification for arched profiles takes longer. Call (786) 442-3200 to discuss your project timeline and we’ll coordinate fabrication with your construction schedule.

Does the VLX 100 qualify for energy tax credits?

The NFRC-rated thermal break construction and Low-E glass options may contribute to whole-home energy performance qualifications, but tax credit eligibility depends on the complete assembly meeting current federal thresholds in the year of installation. We provide certified performance data for your tax preparer. For current Pinecrest-specific guidance, call (786) 442-3200 and we’ll share the NFRC ratings applicable to your configuration.

What warranty comes with the Arched / Custom Door?

ViewLux provides a limited lifetime warranty on the aluminum frame and a 20-year warranty on the insulated glass unit, contingent on installation by an authorized partner like Sightline Windows & Doors Pinecrest using AAMA-compliant methods. Our workmanship is warrantied separately for 5 years. Call (786) 442-3200 for complete warranty documentation before you buy.

Can I customize the size?

Yes. The VLX 100 Arched / Custom Door is fabricated to order with no preset maximum span. We measure your rough opening or work from architectural drawings, and ViewLux engineers the frame to that specification. Very large spans may require structural steel reinforcement or engineer-stamped drawings for Pinecrest permitting. Call (786) 442-3200 to schedule a free measurement and feasibility review.

How do I maintain aluminum frames in Pinecrest’s climate?

Rinse frames quarterly with fresh water to remove salt accumulation, wash annually with mild detergent and a soft brush, and lubricate hinges and locks with a silicone-based product twice yearly. Avoid abrasive cleaners or pressure washers, which can damage anodized or powder-coated finishes. The thermal break and quality seals reduce condensation, but prompt drying of any standing water preserves gasket life. Call (786) 442-3200 if you notice finish degradation or seal compromise; early intervention prevents bigger problems.

Get a Quote - VLX 100 Arched / Custom Door in Pinecrest

Arched entryways demand precision. The measurement, the fabrication, and the installation all have to align for the result to look inevitable rather than problematic. Sightline Windows & Doors Pinecrest has installed ViewLux arched systems across Pinecrest, from modest radius single doors to dramatic double-arch statements. We’ll measure your opening, produce shop drawings for your approval, and install to manufacturer warranty standards. Call (786) 442-3200 today to schedule your free on-site consultation and written estimate.

Written by the team at Sightline Windows & Doors Pinecrest, serving Pinecrest and surrounding Miami-Dade communities as an authorized ViewLux installation partner.
